CAPACITY*

• 2wb: 3” max.
• Textile / Suction Hose: 4” max.
• 4ws: 2” max.
• 6ws: 2” max.

CRIMP RANGE

4 - 130 mm (0.157 - 5.118”)

CRIMP FORCE

350 t

OPENING WITH DIES

+54 mm (+2.125”)

COMPLETE OPENING

180 mm (7.086”)

MASTER DIE LENGTH

115 mm (4.523”)

STANDARD DIES

15, 18, 21, 24, 27, 30, 33, 36, 39, 42, 45, 48, 51, 57, 62, 66, 70, 73, 76

NOISE LEVEL

<70 dB A

MOTOR

4 kW

VOLTAGES

• 220/240 V, 3Ph, 50 Hz
• 380/415 V, 3Ph, 50 Hz
• 208/240 V, 3Ph, 60 Hz
• 380/415 V, 3Ph, 60 Hz

DIMENSIONS

765 x 400 x 750 mmCOMPLETE OPENING(30 x 16 x 30”)

NET WEIGHT

262 kg (578 lb)

TECHNICAL FEATURES

• Automatic maintenance alerts
• Cylinder protection against dust - durable design
• Also available as S CRIMP 350 EVO L with 4.0 kW Motor
